MULTISPAN
Ordering codePS24-0.83A
SMPS Power Supplies
PS24-0.83A
Multispan PS24-0.83A SMPS Power Supply (20W)
The Multispan PS24-0.83A is a 20W DIN-rail switch-mode power supply delivering 24V DC at 0.83 A with efficiency >86% @230 V AC and full hiccup-mode protection. 20 W 24 V DC supply with 110 V AC/DC input option.
Also searched as PS24-0.83A, PS24 0.83A. Genuine Multispan PS24-0.83A — price, datasheet, supplier & distributor support across the UAE & GCC, with worldwide export.
- 20W · 24V DC / 0.83 A
- Efficiency >86% @230 V AC
- Wide 100–270 V AC input
- Hiccup overload & short-circuit protection
- Over-voltage & over-temperature protection
- 2.5 KV input/output isolation
Genuine MultispanCE certified
UAE & GCC delivery
Technical Specification
PS24-0.83A specifications
Model
| Model | PS24-0.83A |
|---|---|
| Rated Power | 20W |
| Output | 24V DC / 0.83 A |
| Size (HxWxD) | — |
| Weight | — |
| Mounting | DIN Rail |
Input
| Supply Voltage | 100 to 270V AC ±10% (L-N) |
|---|---|
| Frequency Range | 50 / 60 Hz |
| Efficiency (typ.) | >86% @230V AC |
| Start-up Time | <1 sec @230V AC |
Output
| Nominal Output | 24V DC, 0.83 A |
|---|---|
| Ripple & Noise (max) | <1% of V out |
| Line / Load Regulation | ±1% |
| Adjustment | Front voltage ADJ. trimmer |
Protection
| Overload | 110–140% rated — hiccup mode, auto-recover |
|---|---|
| Short Circuit | Hiccup mode, auto-recover |
| Over Voltage | Latch / auto per model |
| Over Temperature | Auto shutdown & recovery |
| Isolation | 2.5 KV input to output |
